Control
Series F15 Floating Ball Valve with Series 92 Rack and Pinion Pneumatic Actuator and Series 54 Proximity Sensor
Control Ball Valve
V-Control
- Due to the in-line design inherent with characterized control ball valves, line media flows linearly through the piping system.
- The direct pattern provides increased media control and rapid response times to controller commands.
- Flow-Tek offers a wide range of V-Port and Slotted Port characterized balls to meet your control needs.
- V-Control Series ball valves offer bi-directional bubble-tight Class VI shutoff in compliance with FCI 70-2 standards.
- Flow-Tek characterized balls have a minimum rangeability of 200:1 and can exceed 800:1. Flow rates are highly repeatable within the normal 20% – 80% range of travel.
Rack and Pinion Pneumatic Actuator
Series 92/93
- All double acting and spring return units are suitable for both on/off and throttling applications.
- Actuators which can be actuated with other media such as hydraulic oil or water are also available as an option.
- Two independently adjustable travel stop screws and a cam on the output shaft to permit precise bidirectional adjustment of movement in both the open and closed positions for quarter turn valves (+5° to -5° limit adjustment).
- Standard units have anodized aluminum bodies with polyester coated end caps.
Proximity Sensor
Series 54-GS
- The Series 54 proximity sensor provides position indication for quarter turn valves.
- Two independent sensors for open and close valve position indication.
- Optimal design for high pressure washdowns and caustic washdown service.
- Hermetically sealed to protect against the ingress of liquids or solids.
- Suitable for dirty process environments and rapid cycling applications.
- Rugged design resistant to shock, vibration, UV and corrosion.
- Non-contact sensor eliminates the effect of mechanical wear.
- Eliminates potential switch welding, arcing and sparking.
Control
Series 19L Segmented Control Valve with Series 93 Rack and Pinion Pneumatic Actuator and Series 5B Valve status monitor with Device Net
Segmented Ball Valve
Series 19/19L
- Series S19 combines the shearing action of a knife gate valve, control characteristics of a globe valve, and sealing performance of a ball valve in a versatile high-performance rotary control valve designed for throttling and on-off applications.
- Combines the versatile design of the standard S19 with advanced trims for highly abrasive slurry and severe service applications that often lead to erosion in traditional valves.
- Reverse flow direction prevents body wall erosion due to high velocities at low openings.
- Integrates bearing seals to protect from ingress of media.
Rack and Pinion Pneumatic Actuator
Series 92/93
- All double acting and spring return units are suitable for both on/off and throttling applications.
- Actuators which can be actuated with other media such as hydraulic oil or water are also available as an option.
- Two independently adjustable travel stop screws and a cam on the output shaft to permit precise bidirectional adjustment of movement in both the open and closed positions for quarter turn valves (+5° to -5° limit adjustment).
- Standard units have anodized aluminum bodies with polyester coated end caps.
Smart Positioner
Series 6A
- Designed with ease of installation, simple calibration, efficiency and economy in mind.
- Includes Auto Calibration by entering only three parameters into keypad push buttons.
- Setup time in less than 5 minutes and doesn't require a manufactures technician.
- During operation, the unit continually optimizes control behaviors and travel times in response to changes in line media pressure.
- An additional feature of the Series 6A is an internal monitor that transmits a fault signal alarm if the air supply fails. The alarm is shown locally on the LCD and may be sent to the remote control panel.
Control
McCannalok Butterfly Valve with Series 93 Rack and Pinion Pneumatic Actuator and Series 5B Valve Status Monitor
High Performance Butterfly Valve
McCannalok™ Metal Seated
- Available in a metal seat design for abrasive applications and with a soft seat for air and water applications.
- offered in a variety of body styles: Wafer, Lug and Double Flanged.
- Wear-resistant Inconel® 718 metal seat provides industry leading low torque.
- 3rd party validated high temperature tested.
- High strength, anti-blowout one piece stem.
- Nitrided disc for abrasion resistance.
- Contoured disc to maximize flow.
- Full face retaining ring protects seat in abrasive applications.
Rack and Pinion Pneumatic Actuator
Series 92/93
- All double acting and spring return units are suitable for both on/off and throttling applications.
- Actuators which can be actuated with other media such as hydraulic oil or water are also available as an option.
- Two independently adjustable travel stop screws and a cam on the output shaft to permit precise bidirectional adjustment of movement in both the open and closed positions for quarter turn valves (+5° to -5° limit adjustment).
- Standard units have anodized aluminum bodies with polyester coated end caps.
Switch Box
Series 5B
- Designed to provide reliable hydraulic power in remote locations.
- Excellent for Solar powered, consumption solenoid (1.8 watts).
- Configurations for low and high pressure applications.
- Supply voltages include 12 or 24 VDC, 120-220 VAC, 480V 3-Phase 60 Hz.
- Control Signal: 12 or 24 VDC or 120-220 VAC.
Control
Series 21 Resilient Butterfly with Series 70 Electric Actuator with Servo NXT card
Resilient Seated Butterfly Valve
Series 20/21
- Surpasses the high standards required in sanitary valve applications, and inherent flow characteristics and capabilities.
- Designed with Non-corrosive, heavy duty acetal bushing absorbs actuator side thrust.
- One piece design. The disc edge is spherically machined and hand polished to produce a bubble tight shutoff, minimum torque, and longer seat life.
- For erosion and abrasion resistance, the one piece disc/stem is available encased in either EPDM or BUNA-N.
- Two piece wafer or lug style allows for ease of assembly and maintenance.
Electric Actuator
Series 70
- Provides on/off or modulating control.
- UL, CSA and CE certification on most configurations.
- Declutch able manual override handwheel system.
- Highly visible valve status display on top of actuator.
- High torque start motor.
- Designed like a junction box,the Series 70 offeres the easiest access to terminal block wiring, cam adjustments and switch installation in the industry.
Control
Series 39L Control Valve with Series 92 Rack and Pinion Pneumatic Actuator and Series 6A Positioner
Ceramic Lined Butterfly Valve
Series 39
- Offered in both wafer or long body double flanged designs.
- Equipped with an externally adjustable stem packing system that allows packing adjustment without removing the actuator.
- Disc options include Chrome-Molly Iron or PSZ (Partially Stabilized Zirconia) Ceramic for increased wear life.
- Engineered with a blow-out proof stem retention system to assure full retention of the stem in the unlikely event of an internal stem failure.
- Repairable ceramic liner which is bonded to the body and totally encapsulate the body isolating it from the line media to extend cycle life.
Rack and Pinion Pneumatic Actuator
Series 92/93
- All double acting and spring return units are suitable for both on/off and throttling applications.
- Actuators which can be actuated with other media such as hydraulic oil or water are also available as an option.
- Two independently adjustable travel stop screws and a cam on the output shaft to permit precise bidirectional adjustment of movement in both the open and closed positions for quarter turn valves (+5° to -5° limit adjustment).
- Standard units have anodized aluminum bodies with polyester coated end caps.
Smart Positioner
Series 6A
- Designed with ease of installation, simple calibration, efficiency and economy in mind.
- Includes Auto Calibration by entering only three parameters into keypad push buttons.
- Setup time in less than 5 minutes and doesn't require a manufactures technician.
- During operation, the unit continually optimizes control behaviors and travel times in response to changes in line media pressure.
- An additional feature of the Series 6A is an internal monitor that transmits a fault signal alarm if the air supply fails. The alarm is shown locally on the LCD and may be sent to the remote control panel.
Sustainability
McCannalok High Performance Butterfly Valve with Series 98 Pneumatic Actuator and Series 6A Positioner
Resilient Seated Butterfly Valve
Series 3W/3L
- Extended reliability tested to 1,000,000 cycles.
- Upgraded drivetrain components offer superior resistance to galling and fatigue, enabling high cycle performance.
- Seat energizing O-ring provides continued integrity required to ensure tight shutoff in high cycle applications regardless of line pressure.
- Chevron style mated rings are energized constantly to prevent the escape on any line media, thus increasing process efficiency and eliminating the need for unplanned packing adjustments.
Scotch Yoke Pneumatic Actuator
Series 98
- Compact design offers a high torque to weight ratio.
- Modular Design offers easy configuration in the field.
- Cycle tested beyond 1,000,000 cycles.
- Safety certifications include ATEX, SIL 3 suitable.
- Temperature ranges from -50°F (-46°C) to 300°F (149°C) based on material selection.
Smart Positioner
Series 6A
- Designed with ease of installation, simple calibration, efficiency and economy in mind.
- Includes Auto Calibration by entering only three parameters into keypad push buttons.
- Setup time in less than 5 minutes and doesn't require a manufactures technician.
- During operation, the unit continually optimizes control behaviors and travel times in response to changes in line media pressure.
- An additional feature of the Series 6A is an internal monitor that transmits a fault signal alarm if the air supply fails. The alarm is shown locally on the LCD and may be sent to the remote control panel.
Sustainability
Triad 3-Piece Ball Valve with Series 92 Rack and Pinion Pneumatic Actuator with Series 5B Valve Status Monitor
3-Piece Ball Valve
Triad Series
- A wide range of seat materials to meet a broad range of applications.
- Exclusive primary and secondary dual stem seal arrangement.
- Available in full port and standard port models to keep your operations running across multiple applications.
- Dual body seals retained by machined grooves to reduce seal movement and cold flow.
- Anti-static protection device as a standard.
Rack and Pinion Pneumatic Actuator
Series 92/93
- All double acting and spring return units are suitable for both on/off and throttling applications.
- Actuators which can be actuated with other media such as hydraulic oil or water are also available as an option.
- Two independently adjustable travel stop screws and a cam on the output shaft to permit precise bidirectional adjustment of movement in both the open and closed positions for quarter turn valves (+5° to -5° limit adjustment).
- Standard units have anodized aluminum bodies with polyester coated end caps.
Switch Box
Series 5B
- Designed to provide reliable hydraulic power in remote locations.
- Excellent for Solar powered, consumption solenoid (1.8 watts).
- Configurations for low and high pressure applications.
- Supply voltages include 12 or 24 VDC, 120-220 VAC, 480V 3-Phase 60 Hz.
- Control Signal: 12 or 24 VDC or 120-220 VAC.
Sustainability
Tri-Lok Triple Offset Valve
Triple Offset Butterfly Valve
Tri Lok®
- Zero Leakage Shutoff.
- FE certified for ISO 15848-1, API 641, TA Luft.
- API 607 Fire Safe certified
- SIL 3 suitable.
- Tri Lok features a fully replaceable seat and seal ring system extends the overall life of every Tri Lok Triple Offset valve, minimizing downtime without the need for costly offsite repairs or total replacement.
Sustainability
Acris Lined Ball Valve
Acris PFA Lined Ball Valve
Lined Ball Valve
- Engineered for zero leakage shutoff in demanding corrosive and ultra pure industrial applications.
- Rugged, high strength one piece ball and stem prevents blowouts and limits hysteresis for dependable operation.
- Metal-to-metal body joints protect the locked-in liner from damage caused by external forces.
- Anti-static grounding device prevents static buildup for safe operation.
Sustainability
Series 3W/3L Resilient Seated Butterfly Valve with Series 70 Electric Actuator and Ethernet/IP IIOT Services
High Performance Butterfly Valve
McCannalok™
- Features a one-piece body with molded-in seat to increase pressure rating, operate in higher velocity applications and providing end of line capability.
- The 3W/3L offers a high-strength through stem design utilizing an internal disc to stem connection to reduce hysteresis for longer cycle life.
- This profile disc increase product CV rates and reduces seat wear across cycles and repositioning.
- Upper and lower stem bearings support high cycle rates under high pressure applications compared to other RSBFVs.
Electric Actuator
Series 70
- Provides on/off or modulating control.
- UL, CSA and CE certification on most configurations.
- Declutch able manual override handwheel system.
- Highly visible valve status display on top of actuator.
- High torque start motor.
- Designed like a junction box,the Series 70 offeres the easiest access to terminal block wiring, cam adjustments and switch installation in the industry.
Safe Operation
Tri Lok with Series 98H Hydraulic Actuator, Series 98EH Electro Hydraulic Unit and Series 5B Valve Status Monitor
Triple Offset Butterfly Valve
Tri Lok®
- Zero Leakage Shutoff.
- FE certified for ISO 15848-1, API 641, TA Luft.
- API 607 Fire Safe certified
- SIL 3 suitable.
- Tri Lok features a fully replaceable seat and seal ring system extends the overall life of every Tri Lok Triple Offset valve, minimizing downtime without the need for costly offsite repairs or total replacement.
Scotch Yoke Hydraulic Actuator
Series 98H
- SIL 3 suitable.
- ATEX certified.
- Quick Acting operation for ESD.
- Hydraulic Dampening to reduce shock and vibration.
- Modular design offers easy configuration in the field and a wide variety of product options.
- Torque output to up 885.1000 lb-in.
Switch Box
Series 5C
- Certifications include: IP66/67, NEMA Type 4, 4X, cULus, Intrinsic Safety.
- High Visibility Indicator.
- Accommodates up to 6 switches.
- Features a larger body to accommodate up to 20 terminal points for increased customization.
- Housing Secondary seal allows unit to remain weather tight in unlikely event of dome failure.
- Easy cam adjustment, adjust by simply pressing, truning and releasing at the new position. No tools required.
- The visual indication can also be inverted by rotating the indicator 90 degrees.
Safe Operation
Series 940 Unidirectional Knife Gate
Unidirectional Knife Gate Valve
Series 940
- CE/PED and CRN Certified.
- AWWA C520 for use in water, waste water and reclaimed water applications.
- Offers isolation in rugged applications ranging from general purpose to severe media.
- Optional replaceable zero leakage resilient seat
Safe Operation
Series F15/F30 Flanged Ball Double Block and Bleed
Flanged Ball Valve
Series F15/F30
- Designed in accordance with ASMEB16.34 and API 608.
- Bubble tight shutoff tested to API 598.
- Available in a wide variant of trims to suite you application.
- Packing glad is contoured for uniform distrubtion across the packing to prevent leakage across long cycle life.
Safe Operation
Wafer Swing Check
Check Valve Accessory
PEZ SA-4AX: PVC
- Protection to prevent backflow and pump damage.
- Disc designed to achieve fully open position at low flow rates to prevent wear.
- Certifications include API 6FD, CE, CRN, FM, NSF-61, PED, ULC.
- Optional PVC body with passivated stainless steel or titanium internals and position indication lever.
- Engineered for Saltwater, Marine Life Support and Desalination applications.
Safe Operation
Series 31 Resilient Seated Butterfly Valve with Series 70 Electric actuator and Battery Backup
Resilient Seated Butterfly Valve
Series 30/31
- Engineered to provide bidirectional bubble-tight shutoff and isolation of the line media from the stem or valve body.
- Highly certified across multiple industries for safe operation no matter the application. Certifications include: ABS, Bureau Veritas, CE/PED, CRN, DNV, FDA 21 CFR 177.1550, NSF 372, NSF-61.
- Available with Nylon 11 coated disc.
- Stem is retained in the body by means of a unique Stainless Steel Spirolox® retaining ring, a thrust washer and two C-rings, manufactured from brass as standard, stainless steel upon request. The retaining ring may be easily removed with a standard hand tool. The stem retaining assembly prevents unintentional removal of the stem during field service.
Electric Actuator
Series 70
- Provides on/off or modulating control.
- UL, CSA and CE certification on most configurations.
- Declutch able manual override handwheel system.
- Highly visible valve status display on top of actuator.
- High torque start motor.
- Designed like a junction box,the Series 70 offeres the easiest access to terminal block wiring, cam adjustments and switch installation in the industry.
Severe Service
Series 762 Bidirectional Slurry Valve
Bidirectional Knife Gate Valve
Series 762
- Bray Series 762 bidirectional heavy duty slurry valve is designed for demanding high pressure slurry applications.
- Twin elastomer seats and push-through gate design facilitate self-cleaning and prevent media build up.
- Unique J-ring steel-reinforced, elastomer sleeve design provides energized, zero leakage shutoff in both directions. Retaining rings included as standard throughout the entire size range.
- Unrestricted flow path with minimal pressure drop achieved through full port valve design for extended sleeve life.
- Designed with ample clearance for push-through allowing complete gate closure.
Severe Service
Series M4 Severe Service Ball Valve with Series 92 Rack and Pinion Pneumatic Actuator and Series 54 Proximity Sensor
Severe Service Ball Valve
Series M4
- M4 Severe Service ball valves are engineered specifically for Isolation in Vents & Drains Valve applications in the power industry.
- Zero Leakage is defined as no detectable or visible leakage of gas or liquid for a period of three minutes or greater.*
- Standard 4 yr. performance warranty.*
- All pressure containing components are fully traceable.
- Forged heavy walled unibody construction eliminates the body joint and any potential for shell leakage
High Temperature Pneumatic Actuator
Series 92/93-XT
- All double acting and spring return units are suitable for both on/off and throttling applications.
- Actuators which can be actuated with other media such as hydraulic oil or water are also available as an option.
- Two independently adjustable travel stop screws and a cam on the output shaft to permit precise bidirectional adjustment of movement in both the open and closed positions for quarter turn valves (+5° to -5° limit adjustment).
- Extreme Temperature (XT) option for high temperature applications such as steam service , refining and transit tunnel dampers.
Proximity Sensor
Series 54-GS
- The Series 54 proximity sensor provides position indication for quarter turn valves.
- Two independent sensors for open and close valve position indication.
- Optimal design for high pressure washdowns and caustic washdown service.
- Hermetically sealed to protect against the ingress of liquids or solids.
- Suitable for dirty process environments and rapid cycling applications.
- Rugged design resistant to shock, vibration, UV and corrosion.
- Non-contact sensor eliminates the effect of mechanical wear.
- Eliminates potential switch welding, arcing and sparking.
Severe Service
Ezi-Vac ET Slurry Air Relief Valve
Ezi-Vac ET
Slurry Air Relief Valve
- Slurry Air Release Valves The EZI‐Vac valves are designed for many applications, including slurry and water.
- The large port design prevents clogging while the HI‐WEAR seat and float design offer a large sealing area.
- An Anti Surge Float option is available to limit discharge rates to 3.5kPa differential.
- Coated in Interzone 954 2 part epoxy for high corrosion applications.
- Internal lining in Rubber, EPDM or Urethane on request.
- Optional drain / flush point in body HI‐WEAR primary seal allows drip tight sealing under all conditions.
Severe Service
Acris PFA Lined Butterfly Valve with Gear Operator
Acris PFA Lined Butterfly Valve
Lined Butterfly Valve
- PFA lining offers unsurpassed resistance to corrosion, permeation, and microbial contamination.
- Engineered for maximum purity and reliability.
- Offers bidirectional zero leakage shutoff.
- Vacuum Rating to 0.0002 psia.
- Precision engineered disc for increased CV.
- Energized backup liner maintains tight contact pressure for consistent shutoff in high cycle applications.
- Fugitive Emissions certified for ISO 15484-1 & ISO 15848-2.
Severe Service
McCannalok Cryogenic High Performance Butterfly Valve with Series 92 Rack and Pinion Pneumatic Actuator
High Performance Butterfly Valve
McCannalok™ Cryogenic
- Provides industry leading cryogenic sealing technology and performance while being produced to the highest quality standards.
- Designed to handle the most difficult medias in today’s industrial environments — liquid oxygen, liquid natural gas, and other cryogenic liquids
- Advanced Polar® Seat provides strength, flexibility, and unparalleled performance at cryogenic temperatures.
- Industry leading leakage performance, with high cycle capability, at cryogenic temperatures.
- Material compatibility with liquid and gaseous oxygen, certified by third party testing laboratory.
Rack and Pinion Pneumatic Actuator
Series 92/93
- All double acting and spring return units are suitable for both on/off and throttling applications.
- Actuators which can be actuated with other media such as hydraulic oil or water are also available as an option.
- Two independently adjustable travel stop screws and a cam on the output shaft to permit precise bidirectional adjustment of movement in both the open and closed positions for quarter turn valves (+5° to -5° limit adjustment).
- Standard units have anodized aluminum bodies with polyester coated end caps.
Severe Service
Series M1 Severe Service Ball Valve with Series 98H Hydraulic Scotch Yoke Actuator and Series 98EH Elector Hydraulic Unit
Severe Service Ball Valve
Series M1
- Metal seated valve designed to handle a variety of service conditions including high pressure, high temperatures, corrosive and erosive applications.
- Offers live load packings to prevent packing leaks.
- Propriety ball coating technology to maximize service life.
- Capable of handling temperatures up to 1650°F (900°C).
Scotch Yoke Hydraulic Actuator
Series 98H
- SIL 3 suitable.
- ATEX certified.
- Quick Acting operation for ESD.
- Hydraulic Dampening to reduce shock and vibration.
- Modular design offers easy configuration in the field and a wide variety of product options.
- Torque output to up 885.1000 lb-in.
Switch Box
Series 5B
- Designed to provide reliable hydraulic power in remote locations.
- Excellent for Solar powered, consumption solenoid (1.8 watts).
- Configurations for low and high pressure applications.
- Supply voltages include 12 or 24 VDC, 120-220 VAC, 480V 3-Phase 60 Hz.
- Control Signal: 12 or 24 VDC or 120-220 VAC.
Control
Sustainability
Safe Operation
Severe Service
